| I/O (Input / Output) Product Line |
 |
ITE Product Specifications are available in Adobe Acrobat® Format. The viewer is free to download from Adobe's web site. |
| The I/O Product Division is
actively developing a host of advanced I/O series, including LPC I/O, Easy I/O, USB I/O,
ISA I/O. ITE’s full range of Super I/O has featured the complete
function of Hardware Monitor. In addition, in order to fit the specification of
Intel Low-Pin Count, ITE has also developed a series of highly integrated
LPC I/O controllers featuring Game Port, MIDI, two-channel CIR, H/W Monitor and Smart Card
Reader I/F. The development of USB I/O is also in the company’s plan to fill
the market need for USB serial port integration into the I/O chips.
|
 |
| Part No. <Spec.> |
Product Name <Brief Description> |
Feature | Package | Availability |
| IT8679F | Super I/O | PC 98/99 Legacy
I/O+KBC (Discontinued from now till Jan.2000) |
-- | -- |
| IT8680F | Giga I/O | PC 98/99 Legacy
I/O+KBC+RTC (Discontinued from now till Jan.2000) |
-- | -- |
| IT8661F | ISA Super I/O | PC98 Super I/O (w/out KBC&RTC) | 100 PQFP | Now |
| IT8671F | Simple ISA I/O | IT8679F+KBC+Mouse Power Up | 100 PQFP | Now |
| IT8687R | COM Port Buffer Chip | Buffer Chip for IT8680F/IT8681F &IT8679F/IT8671F | 48 SSOP | Now |
| IT8693F | EC-ISA I/O | Legacy I/O+EC | 128 PQFP | Now |
| IT8673F | Advamced ISA I/O | IT8693F-EC, pin compatible with IT8693F | 128 PQFP | Now |
| IT8712F | EC-LPC I/O | LPC I/O+EC | 128 PQFP | Now |
| IT8702F | LPC I/O | IT8712F-EC, pin compatible with IT8712F | 128 PQFP | Now |
| IT8761F | Simple LPC I/O | LPC I/O+KBC+16550+FDC+16 GPIOs | 48 LQFP | Now |
| IT8706R | GPIO IC | 18 GPIOs | 28 SOP | Q2/00 |
| IT8902F | USB I/O | LPC I/O +USB HUB+KBC +Fan control +Smart Card Reader I/F | 128 QFP | Q3/00 |
| IT8912F | EC-USB I/O | IT8902F +H/W Monitor, Pin compatible with IT8902F | 128 QFP | Q3/00 |
| IT8707F | Light LPC I/O | IT8902F -USB HUB, Pin compatible with IT8902F | 128 QPF | Q3/00 |
| IT8903F | Easy USB I/O | IT8707F -Fan control | 100 QFP | Q3/00 |
Note: We recommend that you use the English Operating
System (OS) to print out the PDF file. If you use the Chinese OS, some words or
punctuations might be missing on the printouts.
Contacts:
Asia: Willy Peng / Sales Manager
Tel: [886] (2) 2657-9896 x6058 Fax: [886] (2) 2657-8561
e-mail: willy.peng@ite.com.tw
USA: David Lin / Sales & Marketing Director
Tel: [1] (408) 530-8860 x238 Fax: [1] (408) 530-8861
e-mail: david.lin@iteusa.com
