| IPC (Intelligent Peripheral Controller) Product Line |
 |
ITE Product Specifications are available in Adobe Acrobat® Format. The viewer is free to download from Adobe's web site. |
| This product line features all the highly integrated IPC chip especially designed for Windows® CE operating system. In the past two years, ITE started sampling its IPC series with the IT8101 for Microsoft HPC 2.0, IT8251 for the Palm size PC, IT8172 for Microsoft TV (former TVPAK) application, and IT8161 for China SVCD/DVD plus Internet. The operating systems are developed on the Windows® CE platform and other IA application. |
|
| Part No. <Spec.> |
Product Name <Brief Description.> |
Feature | Package | Availability |
| IT8101E/F-1 IT8101E/F-2 IT8101E/F-3 | HPC Companion Chip | IPC for Hitachi SH7709 Supports LCD +PCMCIA +Miniature Card +IrDA +AFE I/F +PMU +UART |
208 LQFP/ PQFP |
Now |
| IT8368E | PCMCIA Buffer Chip | PCMCIA Buffer chip for Windows® CE development, pairs with the Philips PR31700 MIPS® RISC processor | 128 LQFP | Now |
| IT8888F/ IT8889F |
PCI-to-ISA Bridge Chip | PCI-to-ISA Bridge Controller | 160 PQFP | Now |
| IT8161F-1 IT8161F-2 |
Windows® CE Companion Chip | FDC +IDE +Printer Port +UART +CIR | 208 QFP | Now |
| IT8172G | Advanced Set-Top Box Solution | Core Logic +PCI +LPC I/F +68K I/F +IDE +UART | 436 BGA | Q2/00 |
| IT8251G | Palm Size PC & PDA Companion Chip | LCDC +PCMCIA/CF I/F +ADC +MMC I/F | 256 LBGA | Q2/00 |
| IT8871F | Advanced South Bridge I | PCI-to-ISA Bridge +1Parallel Port | 160 QFP | Q3/00 |
| IT8872F | Advanced South Bridge II | PCI-to-ISA Bridge +1Parallel Por t+2 UARTs | 160 QFP | Q3/00 |
| IT9810R | 810e Clock Generator | Clock Generator for Intel 810e | 48 SSOP | Q2/00 |
| IT9811R | 815 Clock Generator | Clock Generator for Intel 815 | 48 SSOP |
Q3/00 |
Note: We recommend that you use the English Operating
System (OS) to print out the PDF file. If you use the Chinese OS, some words or
punctuations might be missing on the printouts.
